Home > Products > Coaxial Loudspeakers

M Series

M15

Type:1×15"Two-way full range coaxial loudspeakers
Frequency range:46HZ ～ 20kHZ,
Coverage (HxV): 90°×60°
Impedance: 8Ω
Sensitivity(1W at 1m):100dB
Max SPL(1m at SPL):131dB
Power AES / peak:500W/2000W
LF:1×15" Φ 75mm
HF:1×1.7" Φ 44mm
Dimension(W×H×D): 526.9 ×555×373mm
20.74x21.85x14.68in
Weight:24kg/52.8lb

M12
Type：1x12" Two-way full range coaxial loudspeakers
Frequency range：50HZ ～ 20kHZ,
Coverage ( HxV ): 75°×50°
Impedance: 8Ω
Sensitivity(1W at 1m)：100dB
Max SPL(1m at SPL)：130dB
Power AES / peak：450W /1800W
LF：1×12" Φ75mm (Nd)
HF：1×3" Φ 75mm (Nd)
Dimension(W×H×D):458×486×309(mm）
18.03x19.13x12.16in
Weight：18kg/39.6lb

Product Detail

M8
Type：1x8" Two-way full range coaxial loudspeakers
Frequency range：70HZ ～ 20kHZ,
Coverage ( HxV ): 75°×50°
Impedance: 8Ω
Sensitivity(1W at 1m)：100dB
Max SPL(1m at SPL)：125dB
Power AES / peak：230W /920W
LF：1×8" Φ50mm
HF：1×1.7" Φ 44mm
Dimension(W×H×D):308×340×241(mm）
12.12x13.38x9.48in
Weight：8kg/17.6lb

M6
Type：1×6"Two-way full range coaxial loudspeakers
Frequency range：80HZ ～ 20kHZ,
Coverage ( HxV ): 90°×60°
Impedance: 8Ω
Sensitivity(1W at 1m)：100dB
Max SPL(1m at SPL)：131dB
Power AES / peak：180W/720W
LF：1×6" Φ 50mm
HF：1×1.7" Φ 44mm
Dimension(W×H×D):256 ×290×190(mm）
10.07x11.41x7.48in
Weight：8kg/17.6lb
