K Series

K15
Type:1×15" Two-way full range loudspeakers
(Back bass reflex)
Frequency range:40HZ ～ 19kHZ,
Coverage (HxV): 100°×60°
Impedance: 8Ω
Sensitivity(1W at 1m):100dB
Max SPL(1m at SPL):128dB
Power AES / peak:500W/2000W
LF:1×15" Φ 75mm
HF:1×1.7" Φ 44m
Dimension(W×H×D):428 ×679 ×429mm
16.85x26.73x16.88in
Weight:28kg /61.6lb

K12
Type:1×12" Two-way full range loudspeakers
(Back bass reflex )
Frequency range:45HZ ～ 19kHZ,
Coverage (HxV): 100°×60°
Impedance: 8Ω
Sensitivity(1W at 1m):102dB
Max SPL(1m at SPL):123dB
Power AES / peak: 400W/1600W
LF:1×12" Φ 75mm
HF:1×1.7" Φ 44mm
Dimension(W×H×D): 350×559 ×387mm
13.77x22x15.23in
Weight:22kg /48.4lb

Product Detail

K10
Type:1×10" Two-way full range loudspeakers
(Back bass reflex)
Frequency range: 55HZ ～ 18kHZ,
Coverage (HxV): 100°×60°
Impedance: 8Ω
Sensitivity(1W at 1m):100dB
Max SPL(1m at SPL):119dB
Power AES / peak:260W/1040W
LF:1×10" Φ 65mm
HF:1×1.75" Φ 44mm
Dimension(W×H×D): 300×524 ×350mm
11.81x20.60x13.77in
Weight:16.1kg/35.42lb

K8
Type:1×8" Two-way full range loudspeakers
Frequency range:65HZ ～ 18kHZ,
Coverage (HxV): 90°×60°
Impedance: 8Ω
Sensitivity(1W at 1m):101dB
Max SPL(1m at SPL):115dB
Power AES / peak::170W/300W
LF:1×8" Φ 50mm
HF:1×1.4" Φ 36mm
Dimension(W×H×D): 260×450 ×265mm
10.23x17.71x10.43in
Weight:10.7kg /23.54lb

K8
Type：1×8" Two-way full range loudspeakers
Frequency range：65Hz ～ 18kHz,
CoverageH×V： 70°×60°
Impedance： 8Ω
Sensitivity(1W at 1m)：96dB
Max SPL(1m at SPL)：124dB
Power AES / peak：170W /680W
LF:1×8" Φ 50mm
HF:1×1.4" Φ 36mm
Dimension(W×H×D): 260×450 ×265mm
10.23x17.71x10.43in
Weight:10.7kg /23.54lb
